Highlights |
4K UHD (Front) + Full HD (Rear), 2.4-5GHz Wi-Fi, Cloud, External LTE Module (Optional) |
Product Dimensions |
Front: W 118.5 mm (4.67″) x H 36 mm (1.42″) / 106 g (3.74 oz)
Rear: W 67.4 mm (2.65″) x H 25 mm (0.98″) / 25 g (0.88 oz) |
Rear Camera Connection |
Coaxial cable |
Memory Support |
microSD card up to 256GB |
Recording Modes |
– Normal,
– Event (Impact Detection / Speed Limit / Manual),
– Parking Mode (Impact+Region-based Motion Detection, Timelapse+Events) |
Parking Mode |
YES (with 3-wire hardwiring cable – included) |
Parking Mode Event Voice Notifications |
YES |
Imaging Sensor |
Front: 8MP CMOS Sensor
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP) |
Viewing Angle |
Front: Diagonal 162°, Horizontal 136°, Vertical 77°
Rear: Diagonal 139°, Horizontal 116°, Vertical 61° |
Resolution Frame Rate |
Front / Rear
-4K UHD (3840×2140) @30fps / Full HD (1920×1080) @30fps
*Frame rate may vary during Wi-Fi streaming |
Video Codec |
H.264 (AVC) |
Image Quality and Bitrate Front/Rear |
Highest (Extreme): 25+10 Mbps
Highest: 12+10 Mbps
High: 10+8 Mbps
Normal: 8+6 Mbps |
Format Free |
YES (Adaptive) |
Event File Overwrite Protection |
YES (up to 50) |
SD Card Failure Alert |
YES |
Scheduled Reboot |
YES |
Video File Extension |
MP4 |
Wi-Fi |
Built-in (802.11 a.b.g.n.ac) |
Cloud Compatible |
YES |
GPS |
Built-in (Dual Band : GPS, GLONASS) |
Microphone |
Built-in |
Speaker |
Built-in |
Impact Sensor |
3-Axis Acceleration Sensor |
LED Indicators |
Front: Recording LED, GPS LED, BT/Wi-Fi/LTE LED, Front security LED, Proximity Sensing Indicator LED
Rear: Rear Security LED |
Button |
Button: Wi-Fi ON/OFF (Tap)
Proximity sensor: Mic ON/OFF / Trigger Manual Recording / OFF (configurable) |
Operation Temperature |
-20℃ – 70℃ (-4°F – 158°F) |
Storage Temperature |
-20 °C − 80 °C (-4 °F − 176 °F ) |
High Temp Cut Off |
Approx. 75℃ (167°F) |
Backup Battery |
Built-in supercapacitor |
Input Power |
DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption Hour |
Normal Mode (WiFi On/GPS On/2CH): Avg. 455mA/12V
Normal Mode (WiFi Off/GPS On/2CH): Avg. 385mA/12V
Parking Mode (WiFi On/GPS Off/2CH): Avg. 390mA/12V
Parking Mode (WiFi Off/GPS Off/2CH): Avg. 330mA/12V
* Actual power consumption may vary depending on use conditions and environment. |
