Model Name
|
DR750X-2CH LTE PLUS
|
|
Type
|
2 Channels
|
|
Highlights
|
Built-in 4G LTE, Sony STARVIS image sensors
|
|
Product Dimensions
|
Front: Black / Width 137.6 mm x Height 43 mm / 166 g
Rear: Black / Width 67.4 mm x Height 25 mm / 25 g
|
|
Rear Camera Connection
|
Coaxial cable
|
|
Memory support
|
MicroSD card up to 256GB
|
|
Recording Mode
|
• Normal,
• Event (Impact Detection / Speed Limit / Manual),
• Parking Mode (Impact + Region-based Motion Detection, Time Lapse + Events)
|
|
Parking Mode
|
Yes (with add-on Power Solutions)
|
|
Parking Mode Event Voice Notifications
|
Yes
|
|
Imaging Sensor
|
Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP)
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP)
|
|
Viewing Angle
|
Front: Diagonal 139°, Horizontal 116°, Vertical 61°
Rear: Diagonal 139°, Horizontal 116°, Vertical 61°
|
|
Resolution Frame Rate
|
Front: Full HD (1920×1080) @60fps
Rear: Full HD (1920×1080) @30fps
* Frame rate may vary during Wi-Fi streaming.
|
|
Video Codec
|
H.264 (AVC)
|
|
Image Quality and Bitrate Front/Rear
|
Highest (Extreme): 25+10 Mbps
Highest: 12+10 Mbps
High: 10+8 Mbps
Normal: 8+6 Mbps
|
|
Format Free
|
Yes (Adaptive)
|
|
Event File Overwrite Protection
|
Yes (up to 50)
|
|
SD Card Failure Alert
|
Yes
|
|
Scheduled Reboot
|
Yes
|
|
Video File Extension
|
MP4
|
|
WiFi
|
Built-in [802.11n (2.4~2.4835 GHz)]
|
|
Cloud Compatible
|
Yes
|
|
GPS
|
Built-in
|
|
Microphone
|
Buit-in
|
|
Speaker
|
Built-in
|
|
Impact Sensor
|
3-Axis Acceleration Sensor
|
|
LED Indicators
|
Front: Recording LED, GPS LED, LTE/Wi-Fi LED, Front Security LED
Rear: Rear Security LED
|
|
Button
|
Wi-Fi button: turn Wi-Fi ON/OFF.
Format button: format the microSD card (hold until voice prompt, and then hold again).
Proximity sensor: audio recording ON/OFF or Start Manual Event video. Can be deactivated.
All actions are confirmed by a voice prompt.
|
|
Operation Temperature
|
-20℃ – 70℃
|
|
Storage Temperature
|
-20℃ – 70℃
|
|
High Temp Cut Off
|
Approx. 80℃
|
|
Backup Battery
|
Built-in supercapacitor
|
|
Input Power
|
DC 12V – 24V
|
|
Power Consumption Hour
|
Avg. 350 mAh (4.2 Wh at 12 V, when GPS and Wi-Fi are On)
Avg. 300 mAh (3.6 Wh at 12 V, when GPS and Wi-Fi are Off)
* Actual power consumption may vary depending on use conditions and environment.
|
|
Certifications
|
Front: RCM, CE, FCC, PTCRB, ISED, Telec, RoHS, WEEE
Rear: FCC, CE, RoHS, WEEE
Approved by IMDA (Singapore)
|
|
Software
|
BlackVue Viewer
* Windows XP or higher and Mac Yosemite OS X (10.10) or higher
|
|
Application
|
BlackVue Application (Android 4.4.2 or higher, iOS 9.0 or higher)
|
|
Others
|
Built-in 4G LTE module compatible with Nano-SIM.
Frequency Bands: B1,B3,B7,B20.
|
